RE22, RE22-2
Brand : FRYMASTERE4 Electric Fryers RE22,
RE22-2
Specifically designed for high-volume frying and controlled performance, Frymaster’s proprietary self-standing, swing-up elements and precise controls ensure industry-leading energy efficiency with ASTM ratings greater than 83% which far exceed ENERGY STAR® qualification standards and qualify these fryers for energy-saving rebates.
Specifically designed for high-volume frying and
controlled performance
Frymaster’s proprietary self-standing, swing-up elements and precise
controls ensure industry-leading energy efficiency with ASTM ratings greater
than 83%, far exceeding ENERGY STAR® qualification
standards and qualify these fryers for energy-saving rebates.
The thermostat, mounted on the elements, ensures precise temperature readings. The thermostat system
minimizes temperature overshoot maximizing oil life.
The large cold zone and forward sloping bottom help collect and remove sediment
from the frypot to safeguard oil quality and support routine cleaning. A rear flush feature
moves sediment to the front drain valve for easy and thorough removal.
These models will accommodate additional accessories including CM3.5 controller (standard on TC models) and automatic basket
lifts. The fryer cabinet can include an additional spreader
cabinet with an optional heat lamp and holding station.
The TC model electric fryers have advanced electronic switching devices which
pulse the amount of energy required to the electric elements in much smaller
increments than traditional on/off electrical contactors or gas controls. The result: greater
reliability and more precise temperature control. These models also
have an insulated frypot which can reduce standby energy consumption by an
additional 10%, and they come standard with the CM3.5 controller which
ensures pinpoint accuracy of oil temperature and adjusts cooking time for
consistent high-quality production.
แบ่งปันให้เพื่อนของคุณ
Baskets |
Two twin fry baskets per frypot |
Boil-out |
Boil-out temperature control |
Capacity |
Full frypot = 50 lb (25 liter) |
Cold Zone |
Deep cold zone with 1-1/4" IPS ball-type drain valve |
Construction |
Stainless steel frypot, door and cabinet |
Controller |
CM3.5 |
Design |
Open-pot (full or split) design, easy to clean |
Elements |
Proprietary, self-standing, swing-up flat-bar, low-watt density, long-life heating elements with
power interruption if elements are raised |
Frying Area |
Full frypot = 14" x 15-1/2" (35.6 x 39.4 cm) |
Input |
Full frypot = 22 kw |
Legs |
8-1/2" (22 cm) adjustable legs |
Melt cycle |
Automatic melt cycle |
Temperature Probe |
Robust, RTD, 1° compensating temperature probe |
Technical Specifications |
E4 Electric Fryers RE22, RE22-2 |
W x D x H |
15-5/8" x 31" x 45-3/8"
39.7cm x 78.7cm x 115.3cm |
Weight |
190 lb ( 86.2 kg ) |
Power Output |
22.00 N/A |
Power Input Type |
Electric |
Primary Power Input |
208-240 V x 60 Hz x 3 PH |
Certifications |
|
Accessories | |
Basket Lifts |
Automatic basket lifts (units with basket lifts require CM3.5 or 3000 controllers) |
Baskets |
Full and triplet |
Casters |
Set of four |
Controllers |
Digital or SMART4U 3000
controllers |
Chicken/Fish Tray | |
Frypot |
Split frypots |
Frypot Cover | |
Sediment Tray | |
Side Splash Shield | |
Spreader Cabinet |
Stand-alone spreader cabinet |
Top Connecting Strip |
SPEC SHEET | เปิด |
