K503 F

Brand : CARPIGIANI

2 flavour floor-standing machine

Perfect for customers looking for a high performance machine.

This model allows you to pasteurize the dairy product (one side) while keep running the other side (yogurt and/or sorbet)

Extra flexibility
you’ll be able to clean one side only (for example your yogurt and or sorbet), while keep running the dairy product in the other side

Super flexibility
this model reaches max 42 days cleaning interval

แบ่งปันให้เพื่อนของคุณ

Overview
Optional configurations	Self-closing device The dispensers close automatically stopping the flow of ice cream, eliminating any waste and preventing mess Dispensing door with three levers Greater performance with three lever door, where the middle lever allows for Twin Twist option
Features & Benefits	Independent refrigeration system Allows to work with different products in the two cylinders Stainless steel pressurized gear pump in Advanced Thermoplastic Polymer (P model) The pump ensures the best ice cream texture, quality and high overrun, adjustable from 40% to 80% Interactive display Communicates with the operator delivering instructions and data regarding machine performance Removable pump shaft For easier cleaning procedures, maximum hygiene and Reliability Tank agitators Prevent product stratification and helps to reduce foam by maintaining a fluid consistency High efficiency beaters Stainless steel beaters with double spirals and idler for the Pump version Adjustable ice cream flow Adjustable product flow to meet your specific dispensing speed and volume requirements Fountain pump and covered containers for toppings Two fountain pumps for hot topping and two covered containers for cold toppings Direct expansion cooling cylinders Optimize refrigeration efficiency for fast freeze downtime, less waste of product ensuring higher quality and energy saving Defrost system Possibility to heat the cylinders to simplify the cleaning procedure

Technical Characteristics
flavour	2 + 1
Mix Delivery System	Pump
Cylinder Capacity
lt	1,75
Tank Capacity
lt	20 + 20
Hourly production
75 gr portions	800 (production capacity depends on the mix used and the room temperature)
Electrical
Cooling System	Air
Hz	50*
Ph	3*
Volt	400*
Fuse Size A	16
Rated Power Input kW	5.2
Refrigerant
Refrigerant	R452 (alternative solutions available)
Dimensions
W x D x H cm max	72,3 x 109,8 x 152
Net Weight kg	410
Note	Note * other voltages and cycles available upon request. K503 F is produced by Carpigiani with Quality System UNI EN ISO 9001. All specifications mentioned must be considered approximate; Carpigiani reserves the right to modify, without notice, all parts deemed necessary.
