241 SA P SP

Brand : CARPIGIANI

Single flavour self-dispensing counter-top soft serve machine

The 241 machine is a semi-automatic Portion controller

High efficiency components
Achieve top performances and non-stop production

High performance machine
Its best location is in sites with many potential consumers, such as shopping centers, arcades, water parks, amusement parks, etc.

Overrun and consistency control
Different consistency control settings for various mix types and easy adjustable overrun

แบ่งปันให้เพื่อนของคุณ

Overview
Optional configurations	Self-pasteurization With our self-pasteurization system the machine can be cleaned and disassembled 9 times per year Teorema Remote Control It gives very important info about the machine, it facilitates the service system and helps the cleaning schedule Protected dispensing After placing the cup on the cup holder and having selected the flavour, the gelato is dispensed, always in a protected area
Features & Benefits	Direct expansion cooling cylinder Optimizes refrigeration efficiency for fast freeze downtime, less waste of product ensuring higher quality and energy saving Rear chimney and reduced footprint Space optimization and machine installation next to each other Interactive display Communicates with the user giving him instructions and data regarding the performance of the machine Gear pump It pressurizes the mix with air and feeds the production cylinder for a creamier gelato with a high volume increase High capacity cylinder Perfect for all dispensing circumstances, including the moments of greater production pressure Product protection The upper refrigerated tank lid is key locked to prevent product contamination Simplified cleaning Cleaning is facilitated thanks to the possibility of heating the cylinder and to the easy disassembly of the dispensing unit

Technical Characteristics
Flavour	1
Mix Delivery System	Pump
Cylinder Capacity
Lt	1,75 lt
Tank Capacity
Lt	13 lt
Hourly production
75 gr portions	320 (production capacity depends on the mix used and the room temperature)
Electrical
Cooling System	Air (water optional)
Hz	50
Ph	3
Volt	400
Fuse Size A	10 A
Rated Power Input kW	2,9 kW
Refrigerant	R452 (alternative solutions available)
Dimensions
Net Weight kg	176 kg
Note	241 SA P SP is produced by Carpigiani with Quality System UNI EN ISO 9001. All specifications mentioned must be considered approximate; Carpigiani reserves the right to modify, without notice, all parts deemed necessary.
