| Overview | |
| Performance and Quality |
Hard-O-Tronic® 2E-RSI High Efficiency Beater Direct expansion cylinder
Download the catalogue to discover which optional settings
are compatible. |
| Convenience |
LCD display Tank Agitator Coin Acceptor Coin tray Cup holder Arm Standard Cup holder Shortcut parameter helps manager make minor edits to the
quantity of dispensed Soft Serve Ice Cream. Drip tray
Scan the QR Code on the front of the machine to access the
most up to date equipment information: Instruction Manual, Carpi Care kit
& Carpi Clean kit. |
| Savings |
New high-performance electric gearmotors and condensers |
| Safety |
More operational safety and more control during production |
| Hygiene |
Easy cleaning, guaranteed hygiene |
| Technical Characteristics | |
| flavour |
1 |
| Mix Delivery System |
Pump |
| Cylinder Capacity | |
| lt |
1,75 |
| Tank Capacity | |
| lt |
13 |
| Hourly production | |
| 75 gr portions |
320 (production
capacity depends on the mix used and the room temperature). |
| Electrical | |
| Cooling System |
Air (water
optional) |
| Hz |
50* |
| Ph |
3* |
| Volt |
400* |
| Fuse Size A |
10 |
| Rated Power Input kW |
2,9 |
| Refrigerant | |
| Refrigerant |
R452 (Alternative solutions available) |
| Dimensions | |
| Net Weight kg |
220 |
| Note |
Note Other
voltages and cycles available upon request. 241 Magica is produced by Carpigiani
with Quality System UNI EN ISO 9001. All specifications mentioned must be
considered approximate; Carpigiani reserves the right to modify, without
notice, all parts deemed necessary. |
| SPEC SHEET |
