191 Classic
Brand : CARPIGIANISingle flavor counter top machine to produce soft ice cream and
frozen yogurt
Pump or gravity fed, the machine ensures great production
results.
High versatility
Give free space to your imagination and create cups as well as new soft
delights and single portions.
A cool look
The machine can be adapted to all types of shop thanks to its new modern panel.
Overrun and consistency control
Different consistency control settings for various mix types and easy
adjustable overrun.
แบ่งปันให้เพื่อนของคุณ
Overview | |
Optional configurations |
Self-pasteurization With our self-pasteurization system the machine can be cleaned and
disassembled only 9 times per year Teorema Remote Control It gives very important info about the machine, it
facilitates the service system and helps the cleaning schedule Single portions dispensing head With interchangeable nozzles to make single portions and
delights Self closing device The dispenser closes automatically stopping the flow of ice
cream, eliminating any waste and preventing mess Only You Customize your machine with your colours and logo Wash Kit
Optional tap above the tank to facilitate the cleaning
operations |
Features & Benefits |
Stainless steel pressurized gear pump in Advanced
Thermoplastic Polymer (P model) The pump ensures the best ice
cream texture, quality and high overrun, adjustable from 40% to 80% Independent pump transmission (P model) Helps to extend the pump and gears
life and allows flexibility and maximum performance Gravity fed system (G model) Control valves naturally add air
to the mix producing a firm and dry ice cream having an overrun up to 40% Tank agitator Prevents product stratification
and helps to reduce foam by maintaining a fluid consistency Tank rubber lid Light and handy. It facilitates the cleaning and
filling operations. High efficiency beater in POM Single piece for a dry, compact
gelato Adjustable ice cream flow Adjustable product flow to meet
your specific dispensing speed and volume requirements Direct expansion cooling cylinder Optimizes refrigeration efficiency
for fast freeze downtime, less waste of product ensuring higher quality and
energy saving Defrost system Possibility to heat the cylinder
to simplify the cleaning procedure Rear panel chimney (air cooled version)
Allows to optimize space and to
place machines next to each other |
Technical Characteristics | |
Flavour |
1 |
Mix Delivery System |
Pump or Gravity |
Cylinder Capacity | |
Lt |
1,75 |
Electrical | |
Cooling System |
Air, water option |
Hz |
50* |
Ph |
1* |
Volt |
230* |
Fuse Size A |
16 |
Rated Power Input kW |
2,4 |
Refrigerant |
R452; Alternative
solutions available |
Dimensions | |
Net Weight kg |
140 kg for Pump model,
130 kg for Gravity model |
Air-cooled version | W x D x H cm |
50,5 x 75,5 x 83 |
Note |
* other voltages and cycles available upon request 191 Classic is produced by
Carpigiani with Quality System UNI EN ISO 9001. All
specifications mentioned must be considered approximate; Carpigiani reserves
the right to modify, without notice, all parts deemed necessary. |
SPEC SHEET |
